Shell Method About The X Axis

The shell method is a powerful technique in calculus for finding the volume of a solid of revolution, particularly useful when integrating with respect to an axis perpendicular to the axis of revolution. When revolving a region around the x-axis, the shell method involves integrating with respect to y.

Understanding the Shell Method Around the X-Axis

The shell method relies on summing up the volumes of infinitesimally thin cylindrical shells. Imagine slicing the region into vertical strips and then rotating each strip around the x-axis. This creates a cylindrical shell. The volume of each shell is approximately the surface area of the cylinder multiplied by its thickness.

The formula for the shell method around the x-axis is:

$V = 2\pi \int_{c}^{d} y \cdot f(y) , dy$

Where:

• V is the volume of the solid of revolution.
• c and d are the limits of integration along the y-axis, defining the interval over which the region extends.
• y is the radius of the cylindrical shell (the distance from the y-axis to the shell).
• f(y) is the height of the cylindrical shell (the length of the horizontal strip at a given y-value). It represents the difference between the right and left boundaries of the region, expressed as functions of y.

Steps for Applying the Shell Method About the X-Axis

To successfully apply the shell method around the x-axis, follow these steps:

1. Sketch the Region: Draw a clear diagram of the region you are revolving. This helps visualize the problem and determine the limits of integration and the height of the shell.

2. Identify the Axis of Revolution: Confirm that the region is being revolved around the x-axis. This dictates the use of the shell method with respect to y.

3. Express the Boundaries as Functions of y: Rewrite the equations defining the boundaries of the region so that x is expressed as a function of y. This is crucial because you'll be integrating with respect to y. If the region is bounded by curves x = f(y) and x = g(y), where f(y) ≥ g(y) over the interval [c, d], then f(y) is the right boundary and g(y) is the left boundary.

4. Determine the Limits of Integration: Find the y-values where the region begins and ends along the y-axis. These values, c and d, define the interval over which you'll integrate. Find the intersection points of the boundary curves to determine these limits.

5. Set up the Integral: Substitute the expressions for y, f(y), and the limits of integration (c and d) into the shell method formula:

   $V = 2\pi \int_{c}^{d} y \cdot [f(y) - g(y)] , dy$

   Note that [f(y) - g(y)] represents the height of the cylindrical shell at a given y-value.

6. Evaluate the Integral: Evaluate the definite integral. This will give you the volume of the solid of revolution. This step often involves algebraic manipulation and applying standard integration techniques.

Example 1: Revolving a Region Bounded by y = x and y = x² around the X-Axis

Let's find the volume of the solid formed by revolving the region bounded by the curves y = x and y = x² around the x-axis.

1. Sketch the Region: The region is enclosed between the line y = x and the parabola y = x².

2. Identify the Axis of Revolution: The region is revolved around the x-axis.

3. Express the Boundaries as Functions of y: We need to rewrite the equations as x in terms of y.

   • y = x becomes x = y
   • y = x² becomes x = √y (We take the positive square root since we're dealing with the region in the first quadrant)

4. Determine the Limits of Integration: The curves intersect where x = x², which gives us x = 0 and x = 1. Therefore, the y-values of the intersection points are y = 0 and y = 1. These are our limits of integration: c = 0 and d = 1.

5. Set up the Integral: In this case, f(y) = √y (the right boundary) and g(y) = y (the left boundary). The integral becomes:

   $V = 2\pi \int_{0}^{1} y \cdot (\sqrt{y} - y) , dy$

6. Evaluate the Integral:

   $V = 2\pi \int_{0}^{1} (y^{3/2} - y^2) , dy$ $V = 2\pi \left[ \frac{2}{5}y^{5/2} - \frac{1}{3}y^3 \right]_{0}^{1}$ $V = 2\pi \left[ \frac{2}{5}(1)^{5/2} - \frac{1}{3}(1)^3 - (0) \right]$ $V = 2\pi \left[ \frac{2}{5} - \frac{1}{3} \right]$ $V = 2\pi \left[ \frac{6 - 5}{15} \right]$ $V = 2\pi \left[ \frac{1}{15} \right]$ $V = \frac{2\pi}{15}$

Therefore, the volume of the solid of revolution is 2π/15 cubic units.

Example 2: Revolving a Region Bounded by x = y² and x = 4 around the X-Axis

Let's consider the region bounded by x = y² and x = 4, revolved around the x-axis.

1. Sketch the Region: The region is bounded by a parabola opening to the right (x = y²) and a vertical line (x = 4).

2. Identify the Axis of Revolution: The region is revolved around the x-axis.

3. Express the Boundaries as Functions of y: We already have the equations in terms of x = f(y):

   • x = y²
   • x = 4

4. Determine the Limits of Integration: We need to find the intersection points of the curves. Setting y² = 4, we get y = ±2. So, our limits of integration are c = -2 and d = 2.

5. Set up the Integral: In this case, f(y) = 4 (the right boundary) and g(y) = y² (the left boundary). The integral becomes:

   $V = 2\pi \int_{-2}^{2} y \cdot (4 - y^2) , dy$

6. Evaluate the Integral:

   $V = 2\pi \int_{-2}^{2} (4y - y^3) , dy$ $V = 2\pi \left[ 2y^2 - \frac{1}{4}y^4 \right]_{-2}^{2}$ $V = 2\pi \left[ (2(2)^2 - \frac{1}{4}(2)^4) - (2(-2)^2 - \frac{1}{4}(-2)^4) \right]$ $V = 2\pi \left[ (8 - 4) - (8 - 4) \right]$ $V = 2\pi [4 - 4]$ $V = 0$

Wait! A volume of 0? This indicates a problem. Notice that the function (4y - y³) is an odd function, and we are integrating over a symmetric interval. This means the integral evaluates to zero. The problem is that we need to consider only the positive y values and double the result to account for the symmetry about the x-axis. Therefore, we will integrate from y = 0 to y = 2 and multiply the result by 2.

Corrected Integral:

$V = 2 * 2\pi \int_{0}^{2} y \cdot (4 - y^2) , dy$ $V = 4\pi \int_{0}^{2} (4y - y^3) , dy$ $V = 4\pi \left[ 2y^2 - \frac{1}{4}y^4 \right]_{0}^{2}$ $V = 4\pi \left[ (2(2)^2 - \frac{1}{4}(2)^4) - (0) \right]$ $V = 4\pi \left[ (8 - 4) \right]$ $V = 4\pi [4]$ $V = 16\pi$

Therefore, the volume of the solid of revolution is 16π cubic units.

When to Use the Shell Method

The shell method is most advantageous when:

• The axis of revolution is parallel to the axis of integration. In this case, the axis of revolution is the x-axis, and we are integrating with respect to y.
• The function is easier to express in terms of the variable perpendicular to the axis of revolution. For instance, if it's difficult or impossible to solve for y in terms of x, but easy to solve for x in terms of y, the shell method is a good choice.
• Using the disk or washer method would require splitting the integral into multiple parts due to changes in the outer and inner radii.

Common Mistakes and How to Avoid Them

• Incorrectly Expressing Boundaries: The most common mistake is failing to express the boundaries of the region as functions of y when revolving around the x-axis. Always rewrite your equations as x = f(y).
• Incorrect Limits of Integration: Make sure your limits of integration are y-values that define the start and end of the region along the y-axis. Drawing a diagram is crucial to avoid this.
• Forgetting the Radius: Remember that the radius of the cylindrical shell is y when revolving around the x-axis. Don't forget to include this factor in your integral.
• Incorrectly Identifying the Height of the Shell: The height of the shell is the difference between the right and left boundaries, expressed as functions of y: f(y) - g(y), where f(y) ≥ g(y).
• Ignoring Symmetry: Check for symmetry. If the region and the function are symmetric about the x-axis, you can integrate from 0 to the upper limit and double the result, simplifying the calculation. However, remember to check if the function you are integrating is odd or even. If odd over a symmetric interval, the direct integral might result in zero, necessitating adjusting the integration limits and multiplying by two, as illustrated in Example 2.

Alternative Methods: Disk and Washer Methods

While the shell method is useful, the disk and washer methods are alternative techniques for finding volumes of revolution. The choice of method often depends on the orientation of the axis of revolution and the ease with which the functions can be expressed.

• Disk Method: Used when revolving a region where the cross-sections perpendicular to the axis of revolution are solid disks. The volume is found by integrating the area of the disks along the axis of revolution.
• Washer Method: Used when revolving a region where the cross-sections perpendicular to the axis of revolution are washers (disks with a hole in the center). The volume is found by integrating the difference between the areas of the outer and inner disks along the axis of revolution.

If revolving around the x-axis and using the disk/washer method, you would integrate with respect to x, requiring you to express y as a function of x. Comparing the ease of solving for x in terms of y versus y in terms of x often dictates which method is simpler for a given problem.

Advanced Applications and Considerations

The shell method can be extended to more complex scenarios:

• Revolving around a line parallel to the x-axis: If revolving around the line y = k, the radius of the cylindrical shell becomes |y - k|. The integral becomes:

  $V = 2\pi \int_{c}^{d} |y - k| \cdot [f(y) - g(y)] , dy$

• Regions Defined by Parametric Equations: The shell method can be adapted for regions defined by parametric equations. You'll need to express x and y as functions of the parameter and adjust the limits of integration accordingly.

• Improper Integrals: In some cases, the limits of integration may be infinite, leading to an improper integral. You'll need to use techniques for evaluating improper integrals to find the volume.

Conclusion

The shell method is a valuable tool for calculating volumes of solids of revolution, particularly when revolving around the x-axis and integrating with respect to y. By understanding the underlying principles, following the steps carefully, and avoiding common mistakes, you can effectively apply the shell method to solve a wide range of problems. Remember to always visualize the problem, correctly express the boundaries as functions of y, and choose the appropriate limits of integration. Practice with various examples to master this technique and gain confidence in your calculus skills.
