Graph That Is Not A Function

Graphs are powerful visual tools used to represent relationships between variables. While many graphs represent functions, it's crucial to understand that not all graphs do. A graph that isn't a function fails to meet the specific criteria required to be classified as one. The concept hinges on the vertical line test and the uniqueness of output values for each input. Let's delve into the intricacies of graphs that don't represent functions, exploring their characteristics, examples, and underlying principles.

What Defines a Function?

To understand what makes a graph not a function, we first need to solidify the definition of a function itself.

A function is a relationship between a set of inputs (called the domain) and a set of possible outputs (called the range) with the property that each input is related to exactly one output. In simpler terms:

• For every x-value (input), there can be only one corresponding y-value (output).

This "one-to-one" or "many-to-one" mapping is what distinguishes a function from a more general relation. Relations, in mathematics, are simply sets of ordered pairs. A function is a special type of relation.

The Vertical Line Test: A Visual Determination

The vertical line test provides a quick and easy visual method for determining if a graph represents a function.

The Vertical Line Test states: If any vertical line drawn on the graph intersects the graph at more than one point, then the graph does not represent a function.

Why does this work?

A vertical line represents a single x-value. If the vertical line intersects the graph at two or more points, it means that for that single x-value, there are multiple corresponding y-values. This violates the fundamental definition of a function, which requires each input to have only one output.

Examples of Graphs That Are Not Functions

Let's explore several examples of graphs that fail the vertical line test and are, therefore, not functions.

1. Circles:

The equation of a circle centered at the origin is given by:

x² + y² = r²

where r is the radius of the circle.

If you draw a vertical line through any part of the circle (except at the extreme left and right points), the line will intersect the circle at two points. This means that for a single x-value, there are two y-values: a positive one and a negative one. Thus, a circle is not a function.

Example: Consider the circle x² + y² = 25 (radius 5). If x = 3, then:

3² + y² = 25 9 + y² = 25 y² = 16 y = ±4

So, when x = 3, y can be either 4 or -4. This demonstrates that a single input (x = 3) has two outputs (y = 4 and y = -4), violating the function rule.

2. Ellipses (with vertical major axis):

An ellipse, similar to a circle, generally does not represent a function. The standard form of an ellipse centered at the origin is:

(x²/a²) + (y²/b²) = 1

where a is the semi-major axis and b is the semi-minor axis. If the ellipse is oriented with its major axis along the y-axis (i.e., b > a), it will definitely fail the vertical line test. Even with a horizontal major axis, unless highly compressed, it is likely to fail.

3. Parabolas (opening sideways):

The standard equation of a parabola opening to the right is:

y² = 4ax (where a is a constant)

Unlike parabolas that open upwards or downwards (which are functions), a sideways parabola fails the vertical line test. For any x-value greater than 0, there will be two corresponding y-values (one positive and one negative).

Example: Consider y² = 4x. If x = 1, then:

y² = 4(1) y² = 4 y = ±2

So, when x = 1, y can be either 2 or -2. Again, a single input has two outputs.

4. Inverse Trigonometric Functions (without restricted domains):

The inverse trigonometric functions (arcsin, arccos, arctan, etc.) are not functions over their entire natural domains. For example, consider arcsin(x), also written as sin⁻¹(x). To make these functions well-defined, we usually restrict their domains.

• arcsin(x): The principal value of arcsin(x) lies between -π/2 and π/2. Without this restriction, for a single x-value, there are infinitely many angles whose sine is that value.

• arccos(x): The principal value of arccos(x) lies between 0 and π. Similar to arcsin(x), multiple angles can have the same cosine value.

Therefore, if the domain is not restricted, the graphs of inverse trigonometric functions will fail the vertical line test and are not functions.

5. The Relation x = y²:

This is a simple algebraic example. If you solve for y, you get:

y = ±√x

This immediately tells you that for any positive x-value, there will be two y-values (one positive and one negative). This is precisely the definition of something that is not a function.

6. Graphs with Vertical Lines:

A vertical line itself is a relation but not a function. A vertical line has the equation x = c, where c is a constant. This means that for that single x-value (c), there are infinitely many y-values. This is a blatant violation of the function definition.

7. Piecewise Defined Relations:

You can construct piecewise defined relations that are not functions. For example:

y = x + 1,  if x < 2
y = 3,    if x = 2
y = -x + 5, if x > 2

This is a function. However, consider this example:

y = x + 1,  if x < 2
y = 3,    if x = 2
y = -x + 5, if x > 2
y = 10,   if x = 2

Now, when x = 2, y can be either 3 or 10. This fails the vertical line test at x = 2 and is not a function.

8. "S"-Shaped Curves or Figures-of-Eight (Lemniscates):

Many curves that loop back on themselves will fail the vertical line test. For example, a lemniscate (figure-of-eight) has an equation like (x² + y²)² = a²(x² - y²). Such curves will generally have regions where a single x-value corresponds to multiple y-values.

Why Does It Matter? The Importance of Functions

The concept of a function is fundamental in mathematics and many other fields. Here's why distinguishing functions from non-functions is important:

• Predictability and Uniqueness: Functions provide a predictable and unique relationship between inputs and outputs. This is crucial for modeling real-world phenomena. If a relationship is not a function, it means that for a given input, you can't be certain of the output, which makes analysis and prediction difficult.

• Mathematical Operations: Many mathematical operations and theorems are specifically defined for functions. Calculus, for instance, relies heavily on the properties of functions, such as continuity and differentiability. You can't directly apply these tools to relations that are not functions.

• Computer Science: Functions are a cornerstone of programming. They allow you to encapsulate a specific task or calculation into a reusable block of code. The reliable input-output relationship of a function is essential for writing correct and maintainable software.

• Modeling and Analysis: Functions are used to model a vast array of real-world phenomena, from the trajectory of a projectile to the growth of a population. Using a relation that is not a function to model such a situation would lead to inaccurate and unreliable results.

Expressing Non-Functions with Parametric Equations

While a relation that is not a function cannot be expressed as a single equation y = f(x), it can often be represented using parametric equations. Parametric equations define x and y as functions of a third variable, often denoted by t (the parameter).

For example, a circle can be represented parametrically as:

x = r cos(t) y = r sin(t)

where r is the radius and t varies from 0 to 2π.

Although neither x nor y is a function of the other directly, both are functions of the parameter t. This allows us to describe complex shapes that are not functions in the traditional y = f(x) form.

How to Convert a Non-Function into Multiple Functions

Sometimes, we can "break down" a non-function into multiple functions by restricting the range. Consider the example of y² = x. As we discussed earlier, this is not a function because for every positive x, there are two y-values. However, we can define two separate functions:

• f₁(x) = √x (the positive square root)
• f₂(x) = -√x (the negative square root)

Each of these is a function because for every x, there is only one y. By considering them separately, we can still work with these relationships in a functional way. This is commonly done with inverse trigonometric functions by restricting their range to principal values.

Common Misconceptions

• All equations are functions: This is false. Only equations that pass the vertical line test when graphed are functions.

• If an equation has both x and y, it's not a function: This is also false. Many functions have both x and y in their equation (e.g., y = x² + 2x + 1).

• Functions must be linear: Absolutely not. Functions can be linear, quadratic, trigonometric, exponential, logarithmic, or any other type of relationship.

• A graph crossing the x-axis means it's not a function: The x-intercepts of a graph have no bearing on whether or not it's a function. It is the y-values that matter.

Advanced Considerations

• Multivalued Functions: In some advanced areas of mathematics, particularly complex analysis, the concept of a "multivalued function" is used. These are not functions in the traditional sense, as a single input can have multiple outputs. However, they are treated as functions by carefully defining "branches" to make them single-valued within specific regions.

• Implicit Functions: An implicit function is a relation where y is not explicitly defined in terms of x (i.e., not in the form y = f(x)). For example, x² + y² = 1 is an implicit function. While it doesn't explicitly define y as a function of x, we can sometimes find a function (or functions) that satisfy the relation. However, the entire relation itself is not a function.

Conclusion

Understanding the distinction between graphs that represent functions and those that don't is a fundamental concept in mathematics. The vertical line test provides a simple visual tool for making this determination. Recognizing when a graph is not a function is crucial for applying mathematical operations correctly, building accurate models, and ensuring predictability in various applications. While non-functions may not conform to the strict definition of a function, they can often be represented using parametric equations or broken down into multiple functions by restricting the domain. By understanding these principles, you can better analyze and interpret the relationships represented by graphs in various fields of study.
