Algebra 2: Sketching the Graph of Each Function

Sketching graphs is a fundamental skill in Algebra 2, providing a visual representation of functions and their behavior. It allows us to understand key characteristics like intercepts, turning points, and asymptotes, and how these elements contribute to the overall shape of the graph. Mastering the art of sketching graphs not only solidifies your understanding of functions but also aids in solving real-world problems modeled by these functions.

1. Linear Functions

Linear functions are the most straightforward type of function to graph. They have the general form:

f(x) = mx + b

Where:

• m is the slope, representing the rate of change of the function.
• b is the y-intercept, the point where the line crosses the y-axis.

Steps to Sketch a Linear Function:

1. Identify the slope (m) and y-intercept (b).
2. Plot the y-intercept (0, b) on the coordinate plane. This is your starting point.
3. Use the slope to find another point. Remember that slope is "rise over run." From the y-intercept, move up (or down if the slope is negative) by the amount of the rise and move to the right by the amount of the run. Plot this new point.
4. Draw a straight line through the two points. Extend the line in both directions to represent the entire function.

Example:

Sketch the graph of f(x) = 2x - 1.

1. Slope (m) = 2, y-intercept (b) = -1
2. Plot (0, -1).
3. From (0, -1), move up 2 units and right 1 unit to find the point (1, 1). Plot (1, 1).
4. Draw a straight line through (0, -1) and (1, 1).

2. Quadratic Functions

Quadratic functions have the general form:

f(x) = ax² + bx + c

Where:

• a, b, and c are constants, and a ≠ 0.
• The graph of a quadratic function is a parabola.

Key Features of a Parabola:

• Vertex: The highest or lowest point on the parabola. The x-coordinate of the vertex is given by x = -b / 2a. Substitute this value back into the function to find the y-coordinate of the vertex.
• Axis of Symmetry: A vertical line that passes through the vertex, dividing the parabola into two symmetrical halves. Its equation is x = -b / 2a.
• Y-intercept: The point where the parabola crosses the y-axis. It occurs when x = 0, so the y-intercept is (0, c).
• X-intercepts (Roots/Zeros): The points where the parabola crosses the x-axis. They occur when f(x) = 0. You can find them by factoring the quadratic, using the quadratic formula, or completing the square.

Steps to Sketch a Quadratic Function:

1. Determine the direction of opening. If a > 0, the parabola opens upward (has a minimum). If a < 0, the parabola opens downward (has a maximum).
2. Find the vertex. Use the formula x = -b / 2a to find the x-coordinate of the vertex. Then, substitute this value into the function to find the y-coordinate.
3. Find the axis of symmetry. This is the vertical line x = -b / 2a.
4. Find the y-intercept. This is the point (0, c).
5. Find the x-intercepts (if they exist). Set f(x) = 0 and solve for x. Use factoring, the quadratic formula (x = [-b ± √(b² - 4ac)] / 2a), or completing the square. If the discriminant (b² - 4ac) is negative, there are no real x-intercepts.
6. Plot the vertex, axis of symmetry, y-intercept, and x-intercepts (if any).
7. Sketch the parabola. Draw a smooth curve through the plotted points, ensuring that the parabola is symmetrical about the axis of symmetry.

Example:

Sketch the graph of f(x) = x² - 4x + 3.

1. a = 1 (opens upward).
2. Vertex: x = -(-4) / (2 * 1) = 2. f(2) = 2² - 4(2) + 3 = -1. Vertex is (2, -1).
3. Axis of symmetry: x = 2.
4. Y-intercept: (0, 3).
5. X-intercepts: x² - 4x + 3 = 0. Factoring, we get (x - 1)(x - 3) = 0. X-intercepts are (1, 0) and (3, 0).
6. Plot the vertex (2, -1), axis of symmetry x = 2, y-intercept (0, 3), and x-intercepts (1, 0) and (3, 0).
7. Sketch the parabola.

3. Polynomial Functions

Polynomial functions have the general form:

f(x) = aₙxⁿ + aₙ₋₁xⁿ⁻¹ + ... + a₁x + a₀

Where:

• aₙ, aₙ₋₁, ..., a₁, a₀ are constants, and aₙ ≠ 0.
• n is a non-negative integer called the degree of the polynomial.

Key Features of Polynomial Functions:

• Degree: The highest power of x in the polynomial. The degree determines the end behavior of the graph.
• Leading Coefficient: The coefficient of the term with the highest power of x. The leading coefficient, along with the degree, determines the end behavior.
• X-intercepts (Roots/Zeros): The points where the graph crosses the x-axis. They occur when f(x) = 0.
• Y-intercept: The point where the graph crosses the y-axis. It occurs when x = 0, so the y-intercept is (0, a₀).
• Turning Points: Points where the graph changes direction (from increasing to decreasing or vice versa). A polynomial of degree n can have at most n - 1 turning points.
• End Behavior: Describes what happens to the graph as x approaches positive or negative infinity.

End Behavior Rules:

• Even Degree:
  • If the leading coefficient is positive, both ends of the graph point upward (as x → -∞, f(x) → ∞ and as x → ∞, f(x) → ∞).
  • If the leading coefficient is negative, both ends of the graph point downward (as x → -∞, f(x) → -∞ and as x → ∞, f(x) → -∞).
• Odd Degree:
  • If the leading coefficient is positive, the left end of the graph points downward and the right end points upward (as x → -∞, f(x) → -∞ and as x → ∞, f(x) → ∞).
  • If the leading coefficient is negative, the left end of the graph points upward and the right end points downward (as x → -∞, f(x) → ∞ and as x → ∞, f(x) → -∞).

Steps to Sketch a Polynomial Function:

1. Determine the degree and leading coefficient. Use these to determine the end behavior of the graph.
2. Find the y-intercept. Set x = 0.
3. Find the x-intercepts (roots/zeros). Set f(x) = 0 and solve for x. Factoring is often helpful. If you can't factor easily, you might need to use the Rational Root Theorem or numerical methods.
4. Determine the multiplicity of each root. The multiplicity of a root is the number of times the corresponding factor appears in the factored form of the polynomial.
   • Odd Multiplicity: The graph crosses the x-axis at the root.
   • Even Multiplicity: The graph touches the x-axis at the root but does not cross it (it "bounces" off the x-axis).
5. Find some additional points. Choose values of x between the x-intercepts and to the left and right of the "outermost" x-intercepts. This helps to get a better sense of the shape of the graph.
6. Sketch the graph. Draw a smooth curve through the plotted points, paying attention to the end behavior and the behavior at the x-intercepts. Remember that the graph can have at most n - 1 turning points.

Example:

Sketch the graph of f(x) = x³ - x.

1. Degree: 3 (odd), Leading coefficient: 1 (positive). End behavior: as x → -∞, f(x) → -∞ and as x → ∞, f(x) → ∞.
2. Y-intercept: (0, 0).
3. X-intercepts: x³ - x = 0. Factoring, we get x(x² - 1) = 0, which simplifies to x(x - 1)(x + 1) = 0. X-intercepts are (0, 0), (1, 0), and (-1, 0).
4. All roots have a multiplicity of 1 (odd). The graph crosses the x-axis at each root.
5. Additional points: Let's try x = -0.5 and x = 0.5. f(-0.5) = (-0.5)³ - (-0.5) = 0.375. f(0.5) = (0.5)³ - (0.5) = -0.375.
6. Sketch the graph.

4. Rational Functions

Rational functions have the general form:

f(x) = p(x) / q(x)

Where:

• p(x) and q(x) are polynomial functions, and q(x) ≠ 0.

Key Features of Rational Functions:

• Vertical Asymptotes: Vertical lines where the function is undefined. They occur at values of x where the denominator q(x) is equal to zero but the numerator p(x) is not.
• Horizontal Asymptotes: Horizontal lines that the graph approaches as x approaches positive or negative infinity. The existence and location of horizontal asymptotes depend on the degrees of the numerator and denominator.
  • If the degree of p(x) < the degree of q(x), the horizontal asymptote is y = 0.
  • If the degree of p(x) = the degree of q(x), the horizontal asymptote is y = (leading coefficient of p(x)) / (leading coefficient of q(x)).
  • If the degree of p(x) > the degree of q(x), there is no horizontal asymptote (but there may be a slant asymptote).
• Slant Asymptotes (Oblique Asymptotes): Occur when the degree of the numerator is exactly one greater than the degree of the denominator. To find the slant asymptote, perform polynomial long division of p(x) by q(x). The quotient (ignoring the remainder) is the equation of the slant asymptote.
• X-intercepts (Zeros): The points where the graph crosses the x-axis. They occur when p(x) = 0 and q(x) ≠ 0.
• Y-intercept: The point where the graph crosses the y-axis. It occurs when x = 0.
• Holes: Occur when a factor cancels out in both the numerator and the denominator. To find the location of a hole, set the canceled factor equal to zero and solve for x. Then, substitute this value of x into the simplified function (after canceling the factor) to find the y-coordinate of the hole.

Steps to Sketch a Rational Function:

1. Factor the numerator and denominator.
2. Identify any holes. Cancel out any common factors in the numerator and denominator. Set the canceled factors equal to zero to find the x-coordinate of the hole. Substitute this x value into the simplified function to find the y-coordinate.
3. Find the vertical asymptotes. Set the remaining denominator equal to zero and solve for x.
4. Find the horizontal or slant asymptote. Compare the degrees of the numerator and denominator to determine if a horizontal or slant asymptote exists. Calculate the asymptote's equation.
5. Find the x-intercepts. Set the numerator equal to zero and solve for x.
6. Find the y-intercept. Set x = 0.
7. Create a sign chart. Choose test values in each interval created by the vertical asymptotes and x-intercepts. Determine the sign of the function in each interval (positive or negative). This tells you whether the graph is above or below the x-axis in each interval.
8. Sketch the graph. Draw the asymptotes as dashed lines. Plot the intercepts and any additional points you calculated. Use the sign chart to determine the behavior of the graph in each interval. The graph will approach the asymptotes but will not cross them (unless there's a hole).

Example:

Sketch the graph of f(x) = (x + 2) / (x - 1).

1. Already factored.

2. No holes.

3. Vertical asymptote: x - 1 = 0, so x = 1.

4. Horizontal asymptote: Degree of numerator = degree of denominator. Horizontal asymptote is y = 1/1 = 1.

5. X-intercept: x + 2 = 0, so x = -2.

6. Y-intercept: f(0) = (0 + 2) / (0 - 1) = -2.

7. Sign chart:

   Interval	Test Value	Sign of f(x)
   x < -2	x = -3	+
   -2 < x < 1	x = 0	-
   x > 1	x = 2	+

8. Sketch the graph.

5. Exponential Functions

Exponential functions have the general form:

f(x) = a * bˣ

Where:

• a is the initial value (y-intercept).
• b is the base, and b > 0 and b ≠ 1.
• x is the exponent.

Key Features of Exponential Functions:

• Horizontal Asymptote: The x-axis (y = 0) is the horizontal asymptote when the function is in its basic form. Transformations can shift this asymptote.
• Y-intercept: The point where the graph crosses the y-axis. It occurs when x = 0, so the y-intercept is (0, a).
• Increasing or Decreasing: If b > 1, the function is increasing (exponential growth). If 0 < b < 1, the function is decreasing (exponential decay).

Steps to Sketch an Exponential Function:

1. Identify the base (b) and initial value (a).
2. Determine if the function is increasing or decreasing.
3. Find the y-intercept.
4. Find the horizontal asymptote. For basic exponential functions, this is y = 0.
5. Plot a few additional points. Choose some convenient values of x and calculate the corresponding values of f(x).
6. Sketch the graph. Draw a smooth curve through the plotted points, approaching the horizontal asymptote as x approaches positive or negative infinity.

Example:

Sketch the graph of f(x) = 2ˣ.

1. Base (b) = 2, initial value (a) = 1.
2. Increasing (b > 1).
3. Y-intercept: (0, 1).
4. Horizontal asymptote: y = 0.
5. Additional points: f(1) = 2, f(2) = 4, f(-1) = 1/2.
6. Sketch the graph.

6. Logarithmic Functions

Logarithmic functions are the inverse of exponential functions. They have the general form:

f(x) = log_b(x)

Where:

• b is the base, and b > 0 and b ≠ 1.

Key Features of Logarithmic Functions:

• Vertical Asymptote: The y-axis (x = 0) is the vertical asymptote for basic logarithmic functions. Transformations can shift this asymptote.
• X-intercept: The point where the graph crosses the x-axis. It occurs when f(x) = 0, which means x = 1 for basic logarithmic functions. So the x-intercept is (1, 0).
• Increasing or Decreasing: If b > 1, the function is increasing. If 0 < b < 1, the function is decreasing.
• Domain: Logarithmic functions are only defined for positive values of x. Therefore, the domain is x > 0.

Steps to Sketch a Logarithmic Function:

1. Identify the base (b).
2. Determine if the function is increasing or decreasing.
3. Find the x-intercept. For basic logarithmic functions, this is (1, 0).
4. Find the vertical asymptote. For basic logarithmic functions, this is x = 0.
5. Plot a few additional points. Choose some convenient values of x and calculate the corresponding values of f(x). Remember that logarithmic functions grow very slowly.
6. Sketch the graph. Draw a smooth curve through the plotted points, approaching the vertical asymptote as x approaches 0.

Example:

Sketch the graph of f(x) = log₂(x).

1. Base (b) = 2.
2. Increasing (b > 1).
3. X-intercept: (1, 0).
4. Vertical asymptote: x = 0.
5. Additional points: f(2) = 1, f(4) = 2, f(1/2) = -1.
6. Sketch the graph.

7. Transformations of Functions

Understanding transformations allows you to quickly sketch variations of basic functions. Common transformations include:

• Vertical Shifts: f(x) + c shifts the graph up c units if c > 0 and down c units if c < 0.
• Horizontal Shifts: f(x - c) shifts the graph right c units if c > 0 and left c units if c < 0.
• Vertical Stretches/Compressions: a * f(x) stretches the graph vertically by a factor of a if a > 1 and compresses it vertically by a factor of a if 0 < a < 1. If a < 0, it also reflects the graph across the x-axis.
• Horizontal Stretches/Compressions: f(ax) compresses the graph horizontally by a factor of a if a > 1 and stretches it horizontally by a factor of a if 0 < a < 1. If a < 0, it also reflects the graph across the y-axis.
• Reflections: -f(x) reflects the graph across the x-axis. f(-x) reflects the graph across the y-axis.

To sketch a transformed function, start with the basic function and apply the transformations one at a time. Pay close attention to how the key features of the graph (intercepts, asymptotes, turning points) are affected by each transformation.

Conclusion

Sketching graphs is a valuable skill that enhances your understanding of functions and their behavior. By mastering the techniques outlined above, you'll be well-equipped to visualize a wide range of functions and solve related problems. Remember to practice regularly and pay close attention to the key features of each type of function. Good luck!
